Berthold LB 442 - Menu Structure


  Section 13 Appendix
147
13.6 Menu Structure 13.6.1 Parameter Menu
Belt Speed.:
m/s
sk1: General Data
sk2: Operating Mode
sk1 sk2
more
Time Constant 1
Value : sec
Time Constant 2
Time Constant
for Current Input.
(sk1 & Clear)
Detector / Isotope
Code : 0
Isotope:
Cs137, Am241
Co60,Kr85,Cm244,SR90
sk1: Meas. Parameter
sk2: I/O Config
sk1
sk2
etc.
const. Belt Speed
with Moisture comp.
with Tacho
Config Instrument
Pulse Input
Tacho Input
- Begin Shift : __
- Shifts/Day : __
- Hours/Shift : __
Dig. Out Relay 3:
- Tare Measure
Relay 3
Min/Max :
Hysteresis :
Ext. Mass Counter
Tons per Impuls
Off / 0,01 /
0,1 / 1 / 10
Print out Data
- no
- Print Shift
- Print Minutes
Minute print out
Value : 1 - 999 min
Product selection
No. 1 - 10
Product : 1
Batch weight
Value : t
Current Input limits.
0/4 mA:
20 mA:
Current Input. :
0/4 - 20 mA
Digital Input 1:
•Belt Stop
•Reset massintegr.
•Batch mode
Digital Input 2:
•Extern Tare
•Print Start
•Ext. Prod. 3+4
•Start / Stop + Print
- Batch Ready
- Min / Max
Max. Basis Weight
0.000 g/cm2
Loading at Stop
Output curr.: 0/4 mA
B E R T H O L D
Detector Software
Version 1.03
Factory setting
(press sk1 & Clear)
Parameter Print out?
(press Enter)
Language
B E R T H O L D
LB 442 V2.10
B u l k F l o w
Date & Time
Date : DD.MM.YY
Time : HH.MM
Password
Drive for Tachometer
Wheel
Drive Shaft
Current Input
Forward Feed per
Revolution
Value : mm/rev
Unit selection
t kg kg/m
Error mode
in error case
stop / continue
measurement
Current outp. error
current : Value/Hold
Value : 0 mA
Tacho Pulse/rev
500 / 2500 / 5000
Low Load :
Value : t/h
Product selection
extern / intern
Erase mass-
integrator ?
no / yes
Current Output
0 -20 mA / 4 -20 mA
Current Output limits
0/4 mA : 0,0 t/h
20 mA : 100,0 t/h
Width of belt
Value : m/s
