13.6 Menu Structure
150
13.6.4 Service Menu
sk1: Test calcul.
sk2: I / O - Test
sk1 sk2
more
Test pulse rate:
Value : cps
Results
Output curr.: mA
Value : g/cm2
Set output cur.
Current : mA
View input cur.
Current : mA
Input 1: OFF
Input 2: OFF
Input 3: OFF
Relay 1: ON
Relay 2: ON
Relay 3: ON
Test: Set Detector HV
Value : 0 V
sk1: HV-Adjustment
sk2: Status request
sk1 sk2
more
Save Default
Value : 800 V
Read Default
Value : 800 V
Temp. PT100 °C
Temp. NTC °C
Counts cps
HV : V
sk1: Reset
Detektor
sk2: PT 100 Adjust
sk1 sk2
more
für PT 100 - Adjust.
please press
(sk1 & Clear)
sk1 : Adj. current out
sk2 : Adj. current in
sk1 sk2 exit
Current 1.8mA
Offset 4820
+ - more
Current 18mA
Offset 458
+ - more
Curr. Input Adjust.
set value : 1.80 mA
real Value : 0.00mA
Curr. Input Adjust.
set value : 1.80 mA
real Value : 0.00mA
sk1 : Relay Delay Time
sk2 : Operation Time
sk1 sk2 more
Relay delay time
Value : 50 ms
Last device turn on
Date : 01.02.97
Time : 00:00
sk1: Measure Plateau
sk2: Request Plateau
sk1 sk2
etc.
Plateau-measurement
running
(takes approx 10 minutes)
HV( 500): 817 cps
HV( 560): 884 cps
HV( 620): 923 cps
+ - done
sk1 : Plateau
sk2 : adj. current i/o
sk1 sk2 more
for Detector Reset
please press
(sk1 & Clear)
