Section 6 Evaluation Unit LB 442
67
The current calibration data is lost when the instrument is
reset!
Measuring Parameter
Detector and Isotope
o Detector code:
Detector-specific code number for automatic high voltage control.
Detector list
Scintillator Type Dimensions
mm
Weight
kg
Operating
code
NaI Plastic
LB 4401-01
LB 5401-01
25/25 6 0
X
LB 4401-02
LB 5401-02
40/35 6 0 X
LB 4401-03
LB 5401-03
50/50 18 0 X
LB 4405-01 500 10 22 X
LB 4405-02 750 10.5 22 X
LB 4405-03 1000 13 13 X
LB 4405-04 1250 13.5 13 X
LB 4405-05 1500 15 10 X
LB 4405-06 2000 22 10 X
Interfaces
Slave 1
(Only if Number of detectors
> 1)
Address for slave 1. We recommend to keep standard address 1.
Further addresses have to be used only when more than 1 slave is
connected. Accordingly, you have to enter the same address in the
slave evaluation unit.
Service Menu
See Service Functions on page 95.
