Section 10 Technical Data
85
Inputs/Outputs:
Detector terminal: (2a/2c)
II 2 G [EEx ib] IIC or II 2 G [EEx ib] IIB
The table below shows the highest permissible external
inductivity and capacity:
II 2 G [EEx ib] IIC II 2 G [EEx ib] IIB
Highest per-
missible ex-
ternal induc-
tivity
0.15 mH 1.8 mH
Highest per-
missible ex-
ternal capac-
ity
344 nF 507 nF
The effective inner inductivity is negligible.
Effective inner capacity: 12 nF
For inherently safe installation, the cable ends on the
strip terminal must be protected by a 10 mm long
shrink-down plastic tubing (see also the connection
diagram)
3 digital inputs: passive
1. Belt stop or erase mass integrator (18a/18c)
2. External start tare measurement or print start,
Product 3+4 and Start/Stop and print (20a/20c)
3. External product selection (22a/22c)
Current output: for Load 0/4 - 20 mA isolated (max. 500 Ω)
(26a+/26c-)
Limit value outputs: Relay 2: (12a/12c): Mass counter (pulse length 25 to
450ms, default setting 50ms) Relay 3 (14a/14c): Tare
measurement or Batch Ready or Min/max
Relay 1: (16a/16c): Failure alarm
Loading capacity: at resistive load
AC: Max. 250V, max. 1A, max. 200VA
DC: Max. 300V, max. 1A, max. 60 W
Current input: 0/4 - 20 mA (28a-/28c+)
Speed or moisture
Pulse input: (28a-/28c+)
Pulse tachometer (500 pulses/rev, 2500 pulses/rev,
5000 pulses/rev)
Interfaces: RS 232 on instrument front panel
Port for data transfer from evaluation unit to printer or
PC.
