Beta RR 390 User Manual

4
ADJUSTMENTS
59
GB
CHAPTER 4 ADJUSTMENTS
CONTENTS
Adjusting the home position of the front brake lever..................................60
Adjusting the home position of the brake pedal .......................................60
Adjusting the home position of the clutch lever .........................................60
Adjusting the handlebars ......................................................................60
Gas control adjustment .........................................................................61
Checking and adjusting the steering play ................................................61
Adjusting fork ...................................................................................... 62
Adjusting the rebound damper .......................................................... 62
Adjusting the compression damper ....................................................62
Shock absorber....................................................................................63
Adjusting the hydraulic compression damper (high and low speeds) ...... 63
Adjusting the spring preload ............................................................. 63
Adjusting the hydraulic rebound damper ............................................ 64
Tensioning the chain ............................................................................. 64
Adjusting the idle speed ........................................................................65

Beta RR 390 Specifications

General

Displacement	386 cc
Bore x Stroke	88 mm x 63.4 mm
Compression Ratio	12.5:1
Fuel System	Electronic Fuel Injection
Ignition	DC-CDI
Lubrication	Wet sump
Transmission	6-speed
Clutch	Wet multi-disc
Front Tire	90/90-21
Rear Tire	140/80-18
Ground Clearance	320 mm
Dry Weight	107 kg
Engine Type	Single cylinder, 4-stroke, liquid-cooled
Frame	Molybdenum steel with double cradle split above the exhaust port
Rear Suspension	Monoshock
