Beta RR 390 User Manual

1
GENERAL INFORMATION
13
GB
1
4
2
5
3
C
B
A
6
8
7
LH SWITCH
Dip switch 2 has three positions:
A = lights off
B = low beam on
C = high beam on
Button 3 operates the horn.
Switch 4 is used to stop the engine. Press
the button until the engine stops.
INDICATOR SWITCH
Shifting lever 5 left or right activates the
left or right indicators (if installed). When
released, the lever returns to the central
position. Press it to turn the indicators off.
KICKSTART
Kickstart 6 is fitted to the right-hand side
of the engine.
The upper part of the kickstart can be
oriented.
SIDE STAND
Press down side stand 7 with the foot and
lean the vehicle against it.
Ensure that the ground is solid and the
vehicle stands steadily.
If the vehicle is used off-road, the closed
stand can be further fastened by means of
rubber band 8.
STARTER BUTTON
Starter button 1 is located on the right-
hand side of the handlebars and operate
the electric engine starter. Push the button
until the engine starts.
Do not press the button 1 while the engine
is running.

Beta RR 390 Specifications

General

Displacement	386 cc
Bore x Stroke	88 mm x 63.4 mm
Compression Ratio	12.5:1
Fuel System	Electronic Fuel Injection
Ignition	DC-CDI
Lubrication	Wet sump
Transmission	6-speed
Clutch	Wet multi-disc
Front Tire	90/90-21
Rear Tire	140/80-18
Ground Clearance	320 mm
Dry Weight	107 kg
Engine Type	Single cylinder, 4-stroke, liquid-cooled
Frame	Molybdenum steel with double cradle split above the exhaust port
Rear Suspension	Monoshock
