1
GENERAL INFORMATION
9
GB
Get off the male end wrenches and hexa-
gon socket 3.
With these is possible to unscrew the
screw 4.
Pull the left cover of rear fender and unhook
two rubber band 5. Now the toolkit 6 is
accessible.
To take the tool kit, push the button 1 to
get off the saddle. Pull back the saddle.
Pull the rear side panel 2 to disassemble it.
3
6
5
5
4
1
2
