1.6 Type plate
Position of type plate: left chamber side (seen from front), at the bottom right-hand.
Figure 2: Type plate (example of VDL 115)
Indications of the type plate
(example)
Manufacturer: BINDER GmbH
Chamber name: Vacuum drying oven
Serial No. of the chamber
Nominal temperature
110 °C
Nominal temperature
Type of IP protection acc. to standard EN 60529
Temperature safety device acc. to standard DIN 12880:2007
Class of temperature safety device
Optional: Special application acc. to project no.
Nominal voltage +/- 10% at the indicated power frequency
Explosion proof inner chamber
Explosion proof inner chamber
Ex classification acc. to 2014/34/EU
Ex II 2/3/- G IIB T3 Gb/Gc/- X
Ex classification according to ATEX Directive 2014/34/EU
Max. temp. of inner surface 160 °C
Maximum temperature of the inner surfaces: 160 °C / 320 °F
Temp. class T3
Temperature class acc. to IEC 60079-0 for the entire cham-
Max. operating pressure 100 mbar
Max. operating pressure (heating release )
CE conformity marking
Explosion protection symbol.
Ex classification acc. to ATEX Directive 2014/34/EU
Electrical and electronic equipment manufactured / placed on the
market in the EU after 13 August 2005 and to be disposed of in a
separate collection according to Directive 2012/19/EU on waste
electrical and electronic equipment (WEEE).
Explosion protected inner chamber
EX classification acc. to 2014/34/EU
Ex II 2/3/- G IIB T3 Gb/Gc/- X
Max. temp. of inner surface +160 °C
Max. operating pressure 100 mbar
Project No.
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
E3.1
Serial No. 00000000000000
Made in Germany
