VDL (E3) 09/2019 Page 79/234
8.1.1 Operating functions in normal display
Current operating mode
Text list for information icons
Date,
time, authorization level of
the logged-in user, memory
Quick setpoint entry
Continue to next screen
Back to Normal display
Information
Program start
Setpoint entry
Event list
Display of active alarms
Access to main menu
Figure 23: Operating functions of the MB2 controller in normal display (example values)
