Binder vdl 23 - Equipment and Options (Extract)

VDL (E3) 09/2019 Page 217/234
Chamber size
23
56
115
Electrical data (model versions VDL023-230V, VDL056-230V, VDL115-230V) (continued)
Nominal voltage
(+/-10%)
at 50 Hz power frequency
V
230
230
230
at 60 Hz power frequency
V
230
230
230
Current type
1N~
1N~
1N~
Nominal power
kW
0,90
1,40
1,60
Nominal current
A
3,9
6,1
7,0
Chamber fuse 5 x 20 mm / 250V / time-lag T
A
2 x 6,3
2 x 8
2 x 10
Power plug
Grounded plug
Over-voltage category acc. to IEC 61010-1
II
II
II
Pollution degree acc. to IEC 61010-1
2
2
2
Different electrical data for VD-UL constructed for the USA and Canada
(model versions VDL023UL-120V, VDL056UL-120V, VDL115UL-120V)
Nominal voltage (+/-10%) at 60 Hz power fre-
quency
V 120 120 120
Nominal current
A
7,5
11,7
13,4
Chamber fuse 5 x 20 mm / 250V / time-lag T
A
10
2 x 16
--
Chamber fuse 6.3 x 32 mm / 250V / time-lag T
A
--
--
2 x 20
Power plug
NEMA
5-15P
5-20P
5-20P
Environment-specific data
VDL noise level (mean value)
dB (A)
***
***
***
Energy consumption at 100 °C / 212 °F
Wh/h
130
190
220
*** Data not yet determined
All technical data is specified for unloaded chambers with standard equipment (with aluminum racks) at
an ambient temperature of +22 °C +/- 3 °C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of
+/- 10 %. Technical data is determined in accordance to BINDER Factory Standard Part 2:2015 and DIN
12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right
to change technical specifications at any time.
29.4 Equipment and options (extract)
To operate the VDL vacuum drying oven, use only original BINDER accessories or accessori-
es / components from third-party suppliers authorized by BINDER. The user is responsible for
any risk arising from using unauthorized accessories.
Regular equipment
Microprocessor display program controller MB2 with touch screen
Ethernet interface for computer communication
USB interface
Safety controller (safety device class 2 according to DIN 12880:2007)
Universal connection for inert gas / ambient air inlet „GAS/AIR“, adapter with 8 mm hose olive, with fine-
dosing valve for inert gas / ambient air
Pressure regulator (rear) for sweeping with compressed air
Analog pressure display (manometer) for sweeping with compressed air
Pressure switch for heating release at 100 mbar
Measuring connection (DN 16), rear
2 vacuum expansion racks
Safety glass panel
