Chamber size
23
56
115
External dimensions
Chamber with optional pump module
Width, net
mm / inch
523 / 20.59
637 / 25.10
742 / 29.21
Height, net
mm / inch
1425 / 56.10
1542 / 60.71
1669 / 65.71
Depth, net
mm / inch
491 / 19.33
540 / 21.26
660 / 25.98
Depth, gross (including controller, door handle,
connections, pressure regulator)
mm / inch 632 / 24.88 680 / 26.77 801 / 31.54
Wall clearances
Wall clearance, rear (minimum)
mm / inch
100 / 3.94
100 / 3.94
100 / 3.94
Wall clearance, side (minimum)
mm / inch
100 / 3.94
100 / 3.94
100 / 3.94
Internal dimensions
Width
mm / inch
285 / 11.22
400 / 15.75
506 / 19.92
Height
mm / inch
285 / 11.22
400 / 15.75
506 / 19.92
Depth
mm / inch
295 / 11.61
343 / 13.50
460 / 18.11
Interior volume
l / cu.ft.
24 / 0.85
55 / 1.94
119 / 4.20
Racks
Number of expansion racks (aluminum), series
2
2
2
Number of expansion racks (aluminum), max.
4
5
6
Distance between the racks
mm / inch
53 / 2.09
62 / 2.44
68 / 2.68
Usable space per rack (width x depth)
mm / inch
234 x 280
9.21 x 11.02
349 x 320
13.74 x 12.60
455 x 440
17.91 x 17.32
Permissible load per rack
Kg / lbs
20 / 44
20 / 44
20 / 44
Permissible total load
Kg / lbs
50 / 110
60 / 132
70 / 154
Weight
Weight (empty)
Kg / lbs
73 / 161
106 / 224
161 / 355
Temperature data
Temperature range
degrees above room
temperature
°C / °F 10 / 18 16 / 28.8 10 / 18
up to
°C / °F
110 / 230
110 / 230
105 / 221
Temperature fluctuation at 100 °C / 212 °F
± K
0,1
0,1
0.1
Temperature uniformity (variation) at 100 °C /
212 °F
± K 1,2 1,8 3.0
Heating up time to 100 °C / 212 °F
Min
190
170
330
Vacuum data
Vacuum connection with small flange
DN mm / inch
16
16
16
Measuring access port with small flange
DN mm / inch
16
16
16
Inert gas connection with flow-limiter
Adapter with hose olive
∅ mm / inch
8 8 8
Vacuum range (adjustable)
mbar / inHg
10 to 1100
10 to 1100
10 to 1100
Leak rate
bar/h
/
inHg
/h
1x10
-2
/ 0.295
1x10
-2
/ 0.295
1x10
-2
/ 0.295
Ex Classification
Ex-Classification of the entire chamber
according to ATEX Directive 2014/34/EU
II 2/3/- G IIB T3 Gb/Gc/- X
Electrical data (model versions VDL023-230V, VDL056-230V, VDL115-230V)
Protection type according to EN 60529 - RD4
controller housing
IP 54 54 54
Protection type according to EN 60529 - MB2
controller housing
IP 20 20 20
Protection type, VDL general (type plate)
IP
20
20
20
