3.2 Chamber overview
Figure 3: VDL 115 with MB2 controller
Figure 4: VDL 115 with optional RD4 controller
(A) Area for electrical equipment
(B) Triangular instrument panel with chamber controller
(C) Chamber door
(D) Door handle
(E) Elastic-mounted safety glass window
