Stimulating Electrodes
The Orthosis transmits electrical stimulation through five surface electrodes custom placed
by the clinician to provide optimal wrist and hand movements. See Table 4-1.
• Two electrodes are placed on the ventral aspect of the forearm, to stimulate the flexor
muscles.
• One electrode is placed on the thenar eminence to stimulate the thenar muscle group.
• Two electrodes are placed on the dorsal aspect of the forearm, to stimulate the extensor
muscles.
Table 4-1: H200 Wireless electrodes.
Electrode Target Muscle Motion
#1 Extensor Digitorum (ED) Finger Extension
#2
Extensor Pollicis Brevis (EPB) and/or
Extensor Pollicis Longus (EPL)
Thumb Extension
#3 Thenar Muscle Group (Thenar) Thumb Flexion/Opposition
#4 Flexor Digitorum Superficialis (FDS) Finger Flexion
#5 Flexor Pollicis Longus (FPL) Thumb Interphalangeal (IP) Joint Flexion
