Chapter 6 - Fitting the H200 Wireless Orthosis
Flexor Fitting Panels
1. Select a flexor fitting panel that will elicit the desired hand movement. See Figure 6-18.
• Always start with fitting panel A.
• Use the B or C flexor fitting panel for additional radial stimulation and for better index
finger and/or thumb flexion. See Figure 6-19.
Figure 6-18: Flexor fitting panels.
Ulnar electrode placement A - B - C Radial electrode placement
Figure 6-19: Flexors fitting panel, selection guide.
BA C
