Chapter 4 - The NESS H200 Wireless System
Figure 4-7: H200 Wireless Control Unit digital display and indicators.
Indicators and Digital Display
The Control Unit indicators and digital display are illustrated in Figure 4-7.
Digital Display
Program 2 Indicator
Control Unit
Status Indicator
Program 1 Indicator
RF Communication
Indicator
