Bioness NESS H200 Wireless - H200 Wireless FPL Panel; H200 Wireless FPL Panel Screws

41
Chapter 5 - NESS H200 Wireless Clinician's Kit
Figure 5-5: Wrist insert cover adhered to wrist insert.
Wrist Insert Cover
Wrist Insert
Figure 5-6: FPL panel and FPL panel screw.
FPL #5
Electrode Base
H200 Wireless
FPL Panel and
Screw
H200 Wireless FPL Panel
The Wireless FPL panel fits over the #5 electrode base on the Orthosis. See Figure 5-6.
The FPL panel is for patients who have small wrists, to improve limb contact with the FPL
electrode. The FPL panel is available in right (Rt) and left (Lt) configurations.
H200 Wireless FPL Panel Screws
One H200 Wireless FPL panel screw is needed to attach the H200 Wireless FPL panel to
the Orthosis. See Figure 5-6.
