Chapter 4 - The NESS H200 Wireless System
Table 4-6: H200 Wireless Control Unit digital displays.
The Control Unit digital display shows:
• Stimulation intensity level.
• Clinical program selected.
• Electronic registration status.
• Control Unit battery charging status. See Table 4-6.
Display Description Definition
0–9
Stimulation Intensity Level;
"0" Equals No Stimulation
A–G Clinical Program A–G.
Alternating GREEN Arches Registration in Process
Letter "C" Registration Complete
Letter "E" Registration Error
Letter "U" H200 Wireless Control Unit Unregistered
Rotating GREEN Circle H200 Wireless Control Unit Charging
Horizontal GREEN Line H200 Wireless Control Unit Fully Charged
