39
4. Use rotary to select the OPP ON or OFF followed by .
5. Press several times to exit the menu setting.
When CV to CC protection is tripped during operation, the output will
turn off and the following CV to CC status message will display:
To clear the trip status, press once.
Configure CC to CV Protection
The PVS CC to CV protection monitors the transition between constant
current to constant voltage mode. If this event occurs, the output of the
power supply will turn off.
Follow the steps below to set the CV to CC limit:
1. Press the button and press the button one time until
CONFIG is blinking and press .
2. Press button one time until PROTECT is blinking and press
. The display will then show OVP.
3. Press button four times until CC to CV is displayed.
4. Use rotary to select the CC to CV ON or OFF followed by .
5. Press several times to exit the menu setting.
