BK Precision PVS10005 User Manual

42
9
Voltage
Program
○
A
I
Input 0-5 V / 0-5 kΩ or 0-10 V / 0-10 kΩ for
voltage output setting, full scale input
equals maximum output voltage
10
Current
Program
○
A
I
Input 0-5 V / 0-5 kΩ or 0-10 V / 0-10 kΩ for
current output setting, full scale input
equals maximum output current
11
Voltage
Monitor
○
A
O
Output 0-5 V / 0-10 V represents power
supply output voltage, full scale output
equals maximum output voltage
12
Ground
13
CV/CC
○
L
O
High: constant voltage
Low: constant current
14
Enable−
(Ground)
15
Shutoff
○
L
I
Low to High:
OFF/LOW, no action
ON/LOW, output is off
High to Low:
OFF/LOW, output is off
ON/LOW, no action
16
Power OK
○
L
O
High: output is ON
Low: output is OFF
