BK Precision PVS10005 User Manual

43
21
Local/Analog
State
○
L
O
High: front panel controlled
Low: rear analog controlled
22
Ground
23
Ground
24
Current
Monitor
○
A
O
Output 0-5 V / 0-10 V represents power
supply output current, full scale input
equals maximum output current
Enabling/Disabling External Control
Follow the steps below to configure and enable the external control
interface.
1. Press the button and press the button one time until
CONFIG is blinking and press .
2. Press button three times until EXTCTRL is blinking and
press . Press once again to select ENABLE.
3. Use the rotary knob to select the setting of ACTIVE-AMODE or
ACTIVE-BMODE from NOT ACTIVE and press . If the enable
is set to NOT ACTIVE, all the external control as well as the
analog program control will be disabled.
4. Press several times to exit the menu setting.
AMODE
This mode allows button to be output ON/OFF control. When
