Black Box ServSwitch User Manual

APPENDIX C: SERIAL INTERFACE
137
13 Report Switch Matrix
(Complete Setup)
 Output of 48 values
 0x80 for
„No Output“
 The first 16 values
describe CON Port
Output
(cf. Telegram 3)
 The next 32 values
describe the CPU-
Output
(cf. Telegram 7)
STX, 0x53, ETX STX, 0x53,
<CPU#1>,
<CPU#2>,
…,
<CPU#16>,
<CON#1>,
<CON#2>,
…,
<CON#32>,
ETX
Save / Load Switch
Matrix
14 Save Matrix
Configuration to Flash
STX, 0x66, 0x8C,
<Config File No >,
ETX
ACK
15 Load Matrix
Configuration from
Flash
STX, 0x67, 0x8C,
<Config File No >,
ETX
ACK, ECHO
(contains
Complete Setup)
Assignment of Configuration Files to Telegram
Configuration Files
Config File No
Default.sys 0x80
Config01.sys 0x81
Config02.sys 0x82
Config03.sys 0x83
Config04.sys 0x84
Config05.sys 0x85
Config06.sys 0x86
Config07.sys 0x87
Config08.sys 0x88

Black Box ServSwitch Specifications

General

Connection Type	Wired
Type	KVM
Video Support	VGA
USB Support	Yes
Audio Support	Yes
Compatibility	PC
Switching Method	Push Button
Power Supply	External
Ports	4
