ServSwitch™ DKM
168
Keyboard/ Mouse connector, USB type B
(Socket at Local Unit)
Pin Signal
1 VCC (+5V) Red
2 Data - White
3 Data + Green
4 GND Black
Keyboard/ Mouse connector, USB type A
(Socket at Remote Unit)
Pin Signal
1 VCC (+5V) Red
2 Data - White
3 Data + Green
4 GND Black
