122
LEGACY
Torsion Arm Basket
(Short Arms)
Bundle
Number
70210641
70210641 TORSION ARM & 12-3/4” BASKET ASSEMBLY, SHORT
BOM ID Qty Item No Description
1 2 AM2269 STRIPTILL BASKET MOUNT, SHORT (18-3/4”)
2 1 AM7568 STRIPTILL TORSION SPRING ASSEMBLY
3 1 AM7615 BASKET, STRIPTILL, 12-3/4”
4 2 AP2144 HCFT205-16 BEARING
5 4 BP3012 HEX CAP SCREW, 7/16”-14 X 1-1/2, GRADE 5, PLATED
6 4 BP3016 NUT, HEX, 7/16”-14, GRADE 2, PLATED
7 4 BP3017 WASHER, LOCK, 7/16”, PLATED
8 4 BP3038 NUT, HEX, 5/8”-11, GRADE 2
9 4 BP3039 WASHER, LOCK, 5/8”, PLATED
10 2 BP3042 NUT, HEX, 1/2”-13, GRADE 2, PLATED
11 2 BP3043 WASHER, LOCK, 1/2”, PLATED
12 4 BP3126 HEX CAP SCREW, 1/2”-13 X 1-1/2”, GRADE 5, PLATED
13 2 BP3199 HEX CAP SCREW, 1”-8 X 2-1/2”, GRADE 5, PLATED
14 2 BP3244 NUT, HEX LOCK, 1/2”-13, PLATED
15 2 BP3300 U-BOLT, 5/8”-11 X 2-1/2” X 4”, PLATED
16 2 BP3446 NUT, HEX LOCK, 1”-8, REVERSIBLE, PLATED
To Next Page
