BMS alpha CR - Connection of an External Device

Cleaning
8
Air extraction connection
8.4
119
8.4.1 Connection of an external device
NOTE
The air sampling line must not be used to convey media other than air.
The air sampling line does not have a check valve. The compressor could
be damaged.
1. Close the levers for the delivery rate of the upper and lower air.
2. Switch off the mixer via the multifunction display.
Figure 60: Connect the cleaning device
3. Connect the cleaning gun / cleaning device (1) to the quick coupling (2)
of the air extraction connection.
4. Switch on the voltage supply to the machine using the "Control unit on"
switch.
5. Set the machine to manual mode via the multifunction display.
