Pay attention to the correct sequence when connecting and disconnecting
the jumper cables.
Otherwise a short circuit can damage the electronic system.
The battery is charged while the motor is running, just like in a passenger
vehicle. If the battery is empty in exceptional cases, e.g. when the work
lights are not switched off, you can start the motor of the machine in
conjunction with the battery from the towing vehicle.
1. Make sure that the battery voltage of dispenser battery and machine
battery is identical (12 V).
2. Start the motor in the towing vehicle (donor battery).
3. Connect the positive terminal of the receiver battery to the positive
terminal of the donor battery with a red booster cable.
4. Connect the negative pole of the donor battery to earth (bare metal part
of the machine) using the black booster cable.
5. Start the motor of the machine (see Section "Starting the machine")
6. Disconnect the booster cables in the following order:
− Remove the black booster cable from the ground (body).
− Disconnect the black booster cable from the negative terminal of
the donor battery.
− Disconnect the red booster cable from the positive terminal of the
donor battery.
− Disconnect the red booster cable from the positive terminal of the
receiver battery.
