4.4 Machine
Overview
Figure 14: Interior view of the structure
1
Separator
2
Screw compressor air filter
3
Hydraulics
4
Exhaust gas machine
5
Lubrication system
6
Filter cartridge
7
Compressor with controller
8
Cooling unit
9
Battery
10
Diesel motor
