BMS alpha CR - Machine

3
Technical data
3.2
Machine
32
3.2 Machine
Information
Value
General
Delivery head
Up to approx. 30 floors (depending on material)
Conveyor range
Approx. 180 m
Drive
Deutz TD 2.2
Diesel motor
44.5 kW at 2600 min
-1
Ambient temperature
Max. +50 °C
Min. 0 °C
Fuel
Commercial summer or winter diesel
Filling volume diesel tank
75 l
Hydraulics
Hydraulic circuit
Open
Pump
Gear pump
Height volume
14.0 cm
3
Max. pressure
210 bar
Tank capacity
20 l
Hydraulic oil
BMS
Supercharger
Air volume
6 m
3
/min
Max. pressure
9 bar
Compressor oil
BMS 46 max. capacity 10 l
Electrical system
Voltage
12 V
Battery
12 V 90 Ah
Lighting voltage
Depending on the version: 12 V or 24 V
Cooling
Oil cooler
3 separate circuits for engine oil, compressor oil
and hydraulic oil
System
Open system
Accessories delivery hoses
The delivery hoses must be approved for
Operating pressure
10 bar
Diameter *
50 mm (minimum diameter)
* Only delivery hoses with the same diameter may be used.
