61
Passive codes menu
The Passive diagnostic codes menu displays the diagnostic codes that are
not currently pending. The menu is structured in the same way as the
diagnostic menu. The meaning of the table columns displayed corresponds
to the table columns in the Diagnostic menu (see page 60)
Figure 23: Diagnostic menu
After selection, the Passive diagnostic codes menu is closed and
the submenu is displayed.
Machine internal diagnostic codes
Triggering of the compressor temperature switch
For 5 s no D+ signal with running motor
Emergency stop actuation for less than 1 s
Dome screen switch actuation for less than 1 s
