5. Turn the support wheel (4) with the crank (3) downwards until the
mixing and delivery vessel is standing on the ground with its feet (5).
➢ If necessary, you can place a board underneath.
➢ There are support wheel variants where you must first fold the support
wheel downwards over the support wheel latch.
6. Check whether the support wheel is dirty. If necessary, remove any
adhering dirt.
7. Remove the plug from the socket on the towing vehicle and connect it
to the socket (6) on the carriage shaft.
8. Detach the breakaway cable (7) from the towing vehicle.
9. Open the coupling device by pulling the lever (8) upwards.
