Illustrations (continued)
Figure Title Page
2-5 Centres of mass dimensions (mm) and mass distribution 2-8
2-6 Typical pumping speed and pump power curves for an iH80 2-9
2-7 Typical pumping speed and pump power curves for an iH600 at 50Hz 2-10
2-8 Typical pumping speed and pump power curves for an iH600 at 60Hz 2-11
2-9 Typical pumping speed and pump power curves for an iH1000 at 50Hz 2-12
2-10 Typical pumping speed and pump power curves for an iH1000 at 60Hz 2-13
3-1 Remove the iH system from the pallet 3-5
3-2 Lifting-bolt positions 3-6
3-3 Remove/refit the enclosure panels 3-8
3-4 HCDP headplate cooling-water manifold (as supplied) 3-10
3-5 System arrangement to reduce effective footprint (if required) 3-13
3-6 Fit the pump display terminal 3-17
3-7 Leak-test port positions 3-19
3-8 Reconfigure the iH system for your electrical supply (iH80/iH600 only) 3-21
3-9 Reconfigure the pump-motor terminal-boxes (iH80/iH600 only) 3-23
3-10 Connect the electrical supply cable to the connector mating-half 3-25
3-11 Disconnect box mounting height requirements 3-33
3-12 Disconnect box electrical schematic 3-34
3-13 Disconnect box sub-panel general arrangement 3-36
3-14 Disconnect box cable connections 3-37
3-15 Photohelic spoolpiece 3-39
3-16 Photohelic gauge piping connections 3-40
4-1 Front panel of the pump display terminal 4-2
4-2 Menu logic 4-6
4-3 Switch on menu 4-7
4-4 Switch off menu 4-8
4-5 Normal menu 4-9
4-6 Status menu 4-10
4-7 Control menu 4-12
4-8 Setup menu 4-13
4-9 Run til crash menu 4-16
4-10 Units menu 4-17
4-11 Normal display menu 4-18
4-12 Service menu 4-19
4-13 Serial menu 4-21
4-14 Zero sensors menu 4-22
4-15 Gas valve control menu 4-23
4-16 Manual menu 4-24
4-17 View Status menu 4-27
4-18 Messages menu 4-29
4-19 Warning and alarm messages menu 4-30
6-1 Fit a tube fitting 6-3
6-2 Retighten a tube fitting 6-3
vi iH Dry Pumping Systems
