787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Management, Navigation -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 11.10.3
Push –
• INIT REF – displays page for data initialization or for reference data
• RTE – displays page to input or change origin, destination, route and flight
number
• DEP ARR – displays page to input or change departure and arrival
procedures
• ALTN – displays page to modify destination and route for alternate
diversion
• VNAV – displays page to view or change vertical navigation path data
• FIX – displays page to create reference points on ND map
•LEGS –
• displays page to evaluate or modify lateral and vertical route data
• displays page to correlate route waypoints on the ND
• HOLD – displays page to create holding patterns and display holding
pattern data, or to exit holding pattern
• FMC COMM – displays FMC datalink status page
• PROG – displays page to view dynamic flight and navigation data,
including waypoint and destination ETAs, fuel remaining, and arrival
estimates
• NAV RAD – displays page to view or control navigation radio tuning
• PREV PAGE – displays previous page of multiple page displays (for
example, LEGS pages)
• NEXT PAGE – displays next page of multiple page displays
Illuminated (green) – active data is modified but not executed.
Push (while EXEC light is illuminated green) –
• activates data modification(s)
• extinguishes execute light
Multifunction Keypad
Input to the emulated CDUs is done through the multifunction keypads. Two
keypads are provided, one each for the captain and first officer. The keypads are
located on the forward aisle stand adjacent to the lower MFD. (Refer to
Multifunction Keypad (MFK)
in Chapter 10, Section 10, for additional
information.)
1
CDU Function Keys
2
Execute Light
3
Execute (EXEC) Key
