787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.10.45
Note: WXR and TERR are not selectable at the same time.
Note: Selections that are common to both MAP and PLAN modes retain their
states when changing between the two formats. Selections also retain their
states when changing to a different MFD display and then back to a ND
mode.
VSD – Vertical Situation Display.
WXR (Weather Radar) – displays weather radar information. (Weather Radar
, Ch.
11, Sec. 10)
TERR (Terrain) – displays terrain data. (GPWS Look-Ahead Terrain Alerting
Display and Annunciations, Ch. 15, Sec. 10)
TFC (Traffic) – displays TCAS information. (Traffic Alert and Collision
Avoidance System (TCAS), Ch. 15, Sec. 10)
APT (Airport) – displays airports on all ranges.
WPT (Waypoint) – displays waypoints when the ND is in the 10, 20 or 40 NM
range.
STA (Stations) –
• displays high and low altitude navigation aids, when the ND is in the 10,
20 or 40 NM range
• displays high altitude navigation aids, when the ND is in the 80, 160, 320,
or 640 NM range
POS (Position) –
• displays IRS and GPS positions
• displays VOR raw data radials extended from the nose of the airplane to
the stations displayed on the CDU NAV RAD page
DATA (Data) –
• displays the entered or procedural altitude and ETAs at each waypoint
• times are based on distance to go and groundspeed. They do not consider
FMC performance predictions and may differ from other FMC ETAs that
do
FIR (Flight Information Regions) – reserved for future development
AIRSP (Airspace) – reserved for future development
Selected (momentary) – removes menu from ND.
2
Map Information Selections
3
EXIT Key
February 15, 2010
