787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Head-Up Display System -
Displays
Copyright © The Boeing Company. See title page for details.
10.12.4 D615Z003-TBC
HUD Reference Speeds
Top of bar indicates minimum maneuvering speed. This airspeed provides:
• 1.3 g maneuver capability to stick shaker below approximately 20,000 ft
• 1.3 g maneuver capability to low speed buffet (or an alternative approved
maneuver capability as preset by maintenance) above approximately
20,000 ft
Displayed with first flap retraction after takeoff.
Note: 1.3 g maneuver capability occurs at 40º of bank in level flight.
1
Takeoff Reference Speeds
2
VNAV Speed Band
3
Flap Maneuvering Speeds
4
Landing Reference Speed
5
Minimum Maneuvering Speed
240
220
200
260
2
123
140
100
160
VR
V2
V1
149
180
140
120
REF
15
5
30/134
5
6
3
7
0
100
8
1
4
160
