7.2.1 Function code 3, reading 16-bit or 32-bit parameters
This function code is used for reading 16-bit or 32-bit values from the frequency inverter.
Request Read 16-bit parameter:
Function code
1 byte
0x03
Start address (dataset / para. no.)
2 bytes
0x0000 – 0x963F
Number of registers
2 bytes
0x0001
Response Read 16-bit parameter:
Function code
1 byte
0x03
Number of bytes
1 byte
0x02
Register value (parameter value)
2 bytes
0 – 0xFFFF
Request Read 32-bit parameter:
Function code
1 byte
0x03
Start address (dataset / para. no.)
2 bytes
0x0000 – 0x963F
Number of registers
2 bytes
0x0002
Response Read 32-bit parameter:
Function code
1 byte
0x03
Number of bytes
1 byte
0x04
Register value (parameter value)
4 bytes
0 – 0xFFFFFFFF
Exception condition response:
Error code
1 byte
0x83
Exception condition code
1 byte
2, 3 or 4
Start address
This field is used for saving the parameter number and dataset number. The parameter number is in
the range between 0 and 1599 and is saved in the 12 least significant bits. The dataset number is in
the range between 0 and 9 and is saved in the 4 most significant bits.
Example:
Parameter 372 (hex. 0x174), dataset 2 (hex. 0x2) is saved as hex. 0x2174.
Start address
Data set
Parameter number
Bits
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
For the above example:
Hex.
0
0
1
0
0
0
0
1
0
1
1
1
0
1
0
0
Bin.
2
1
7
4
Number of registers
This field is used for saving the number of parameters to be written. The value must always be 1,
since only one parameter can be written at a time.
Number of bytes
This field is set to
• 2 for 16-bit parameters
• 4 for 32-bit parameters
Register value
This field contains the 16-bit or 32-bit parameter value.
Parameter values with decimal places are transferred without decimal point. Depending
on the number of decimal places, the values are multiplied by 10, 100 or 1000.
28
