11.4.2 Profile Velocity mode [u/s] (pv)
“Profile velocity mode” (pv) can be selected via Override Modes Of Operation 1454
= 3. In “Profile
velocity mode” (pv), the frequency inverter receives a target speed in
user units per second [u/s].
Relevant parameters:
410
Control word
1279
Threshold Window Time
411
Status word
1457
Override Profile Acceleration
418
Minimum Frequency
1458
Override Profile Deceleration
419
Maximum Frequency
1179
Emergency ramp
1454
Override Modes Of Operation
1176
Ramp time Accel.
1107
Act. Speed
1178
Ramp time Decel.
1276
Velocity Window
1275
Max Slippage
1277
Velocity Window Time
1460
Override Target Velocity pv [u/s]
1278
Threshold Window
The ramp times are specified via parameters 1176…1178.
In “Profile velocity mode” (pv), the mode-specific bits of the control word and the
status word are used as follows:
Control word
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit
0
Switch on
1
Enable voltage
2
Quick stop (Low
active)
3
Enable operation
4
-
5
-
6
-
7
Fault reset
8
Halt
9
-
1
0
-
1
1
-
1
2
-
1
3
-
1
4
-
1
5
-
82
ACU Modbus/TCP 10/13
