3.2 Initialization time
When the frequency inverter is turned on, the communication module must be initialized in addition to
the frequency inverter. The initialization can take up to 20 seconds.
Wait until the initialization phase is complete before starting the communication (RUN
LED).
4 First commissioning
For first commissioning, you should be familiar with the followings steps and the de-
scribed functions:
• Installation of module
Chapter
5.1
• Selection of device control Local/Remote 412
Chapter
11
• Commissioning of device functions via PLC
o Motion Control Override
Chapter
10.1
o Fault Reaction
Chapter
6.3

Fault reset
Chapter
7.3
• Setting reference values:
o Reference speed in speed-controlled con-
figuration x10, x11, x15, x16, x30, x60
Chapter
11.3
o Reference in position configuration x40
Chapter
10 and 11.4
 Velocity Mode
Chapter
11.4.1
 Profile Velocity Mode
Chapter
11.4.2
 Profile Position Mode
Chapter
11.4.3
 Homing Mode
Chapter
11.4.4
 Table Travel record Mode
Chapter
11.4.5
 Mode change
Chapter
10
• Diagnosis:
Chapter
14 and 13.1
18
ACU Modbus/TCP 10/13
