BONFIGLIOLI Active Cube User Manual

The values are entered automatically in the EEPROM of the controller. However, only
a limited number of write cycles is permissible for the EEPROM (approx. 1 million
cycles). When this number is exceeded, the EEPROM will be destroyed.
 Values which are written cyclically at a high repetition rate should be written to
the RAM and not the EEPROM.
In the RAM, the data is not protected against loss of power. Once power supply is
disrupted, the data must be written again.
NOTE
8.2.1 Example: Writing of index parameters
Typically, index parameters are written regularly during commissioning or in simple
positioning applications.
Writing of Parameter Target position/distance 1202 (Type double word), in Index 1
in RAM ( Index 34 for write access) with parameter value 30000.
Index = 1200 + 0x2000 = 0x24B0, Wert (int) = 34 = 0x0022
Index = 1202 + 0x2000 = 0x24B2, Wert (long) = 30000 = 0x0000 7530
If various parameters of an index are to be edited, it will be sufficient to set index
access via parameter 1200 once at the beginning.
8.2.2 Example: Reading of index parameters
In order to read an index parameter, you will have to set the indexing parameter to
the relevant index first, then you can read the parameter.
Reading of Parameter Target position/distance 1202 (type long), in Index 1 with
parameter value 123000.
Index = 1201 + 0x2000 = 0x24B1, Wert (int) = 1 = 0x0001
Index = 1202 + 0x2000 = 0x24B2, Wert (long) = 123000 = 0x0001 E078
If various parameters of an index are to be read, it will be sufficient to set index
access via 1201 once at the beginning.
10/13
ACU Modbus/TCP 43

BONFIGLIOLI Active Cube Specifications

General

Brand	BONFIGLIOLI
Model	Active Cube
Category	Inverter
Language	English

Summary

GENERAL SAFETY INSTRUCTIONS AND INFORMATION ON USE

Designated use

Specifies the inverter's intended design and use in industrial plants and machines.

Misuse

Residual risks

Details hazards that cannot be eliminated despite safety-compliant design, including electrical, thermal risks.

Operator's/operating staff's responsibilities

Organizational measures

Handling and installation

Electrical connections

Safe operation

Outlines safety measures during operation, including cover checks and avoiding unauthorized modifications.

Maintenance and service/troubleshooting

Describes procedures for maintenance, inspections, and repairs, emphasizing qualified personnel.

First commissioning

Assembly/disassembly of communication module

Assembly

Details the process for installing the CM-Modbus/TCP communication module into the frequency inverter.

Disassembly

Modbus/TCP interface

Communication modules

Describes the CM-Modbus/TCP and CM-Modbus/TCP-2P modules and their RJ45 ports.

Setup

Operating behavior in the case of a communication error

Protocol

Supported function codes

Lists Modbus function codes used for reading and writing 16-bit and 32-bit values.

PARAMETER ACCESS

Handling of datasets / cyclic writing of parameters

Handling of index parameters / cyclic writing

EXAMPLE MESSAGES MODBUS/TCP

16-bit access

Provides examples of Modbus/TCP telegrams for reading and writing 16-bit parameters.

32-bit access

Demonstrates Modbus/TCP telegram examples for reading and writing 32-bit parameters.

MOTION CONTROL INTERFACE (MCI) / MOTION CONTROL OVERRIDE (MCO)

Motion Control Override

Functions of Motion Control Interface (MCI)

Covers reference systems, modes of operation, and parameters for MCI.

CONTROL OF FREQUENCY INVERTER

Control via contacts/remote contacts

Details control methods using digital inputs and remote contacts, including status word bits.

Control via state machine

Explains control via the state machine using the control word and status word.

Configurations without Motion Control

Motion control configurations

Explains how motion control configurations use control and status word bits for various modes.

Parameter List

Parameters (Menu “Para”)

Lists all available parameters, their ranges, and related chapters.

APPENDIX

Error messages

Explains error codes, their groups, and meanings for motion control and Ethernet communication.
