7.2.3 Function code 16, write 16-bit parameter
Function code 16 can be used for writing 16-bit values into the frequency inverter.
Request Write 16-bit parameter:
MBAP header
7 bytes
Address
1 byte
1 – 0xF7 (=247)
Function code
1 byte
0x10
Start address (dataset / para. no.)
2 bytes
0x0000 – 0x963F
Number of registers
2 bytes
0x0001
Number of bytes
1 byte
0x02
Register value (parameter value)
2 bytes
0 – 0xFFFF
Response:
MBAP header
Address
1 byte
1 – 0xF7 (=247)
Function code
1 byte
0x10
Start address (dataset / para. no.)
2 bytes
0x0000 – 0x963F
Number of registers
2 bytes
0x0001
Exception condition response:
MBAP header
Address
1 byte
1 – 0xF7 (=247)
Error code
1 byte
0x90
Exception condition code
1 byte
2, 3 or 4
Start address
This field is used for saving the parameter number and dataset number. The parameter number is in
the range between 0 and 1599 and is saved in the 12 least significant bits. The dataset number is in
the range between 0 and 9 and is saved in the 4 most significant bits.
Example:
Parameter 372 (hex. 0x174), dataset 2 (hex. 0x2) is saved as hex. 0x2174.
Start address
Data set
Parameter number
Bits
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
For the above example:
Hex.
0
0
1
0
0
0
0
1
0
1
1
1
0
1
0
0
Bin.
2
1
7
4
Register value
This field is used for saving the 16-bit parameter value.
Parameter values with decimal places are transferred without decimal point. Depending
on the number of decimal places, the values are multiplied by 10, 100 or 1000.
Example:
A current value of 10.3 A is to be transferred. The actually transferred numerical value is 103, i.e.
0x67 in the hexadecimal system.
10/13
ACU Modbus/TCP 31
