9.2.4 Function code 101 (=0x65), write 32-bit parameter
Example 1:
Writing of parameter
Rated Frequency 375 (0x0177) in dataset 2 of frequency inverter with address
1.
The Rated Frequency is to be set to 10.00 Hz. Parameter
Rated Frequency 375 has two decimal plac-
es. Thus the value to be sent is 1000 = 0x03E8.
Request: Master  frequency inverter
Field:
MBAP
Unit
ID
Func.
DSet/
Par.No.
Par. value
Transaction ID
Protocol
ID
Length
Hex
nn
nn
nn
nn
00
08
01
65
21
77
00
00
03
E8
Response: Frequency inverter  Master
Field:
MBAP
Unit
ID
Func.
DSet/
Par.No.
Par. value
Transaction ID
Protocol
ID
Length
Hex
nn
nn
nn
nn
00
08
01
65
21
77
00
00
03
E8
The response is the reflected signal of the request message.
Example 2:
Writing of non-permissible value 9.00 Hz in parameter
Rated Frequency 375 in dataset 2 of frequency
inverter with address 1.
Parameter
Rated Frequency 375 has 2 decimal places. Thus the value to be sent is 900 = 0x0384.
Request: Master  frequency inverter
Field:
MBAP
Unit
ID
Func.
DSet/
Par.No.
Par. value
Transaction ID
Protocol
ID
Length
Hex
nn
nn
nn
nn
00
08
01
65
21
77
00
00
03
84
Error response: Frequency inverter  Master
Field:
MBAP
Unit ID
Func.
Excep.
Transaction ID
Protocol ID
Length
Hex
nn
nn
nn
nn
00
03
01
E5
04
The sent exception condition code is the hexadecimal value 0x04 = ERROR SLAVE DEVICE.
