BONFIGLIOLI Active Cube User Manual

7.2.7 Function code 8, diagnosis
This function code is used for accessing the Modbus diagnosis counter of the frequency inverter. Each
counter can be accessed via a sub-function code and a counter number. Each counter can be deleted
by entering the hexadecimal sub-function code 0x0A.
The following sub-function codes are supported.
Sub-function
Name
Description
0x0A
Delete all counters
Resets all counters to 0
0x0B
Return number of bus messages
Number of valid messages received
(including all addresses)
0x0C
Return number of bus transfer errors
Number of messages with CRC or pari-
ty/block check/data loss errors
0x0D
Return number of bus exceptions
Number of exception responses sent
0x0E
Return number of slave messages
Number of messages received (including
slave address)
0x0F
Return number of “Slave – no response”
messages
Number of broadcast messages received
0x10
Return number of slave NAK (negative
receipt acknowledgment)
Not used, return value will always be 0
0x11
Return number of “Slave busy” messag-
es
Not used, return value will always be 0
0x12
Return number of bus character data
loss error
Number of messages with data loss
errors
Request (sub-function 0x0A, Delete all counters):
MBAP Header
Address
1 byte
1 – 0xF7 (=247)
Function code
1 byte
0x08
Sub-function
2 bytes
0x000A
Data
2 bytes
0x0000
Response:
MBAP Header
Address
1 byte
1 – 0xF7 (=247)
Function code
1 byte
0x08
Sub-function
2 bytes
0x000A
Data
2 bytes
0x0000
Exception condition response:
MBAP Header
Address
1 byte
1 – 0xF7 (=247)
Error code
1 byte
0x88
Exception condition code
1 byte
1, 3 or 4
Data
This field will always be 0x0000.
36
ACU Modbus/TCP 10/13
