14.4 Application warning messages
When the highest bit of the warning message is set, an “Application warning message” is present.
The application warning messages are bit-encoded as per the following pattern via parameter Appli-
cation warnings
274. Parameter Application warnings 273
indicates the warnings as plain text in
the control panel and the VPlus PC control software.
Use parameter Application warnings 274 in order to read the warning messages via Field Bus.
Application warning messages
Bit no.
Warning
code
Description
0
0x0001
BELT
- V-belt
1
0x0002
SW-LIM CW
– SW limit switch clockwise
2
0x0004
SW-LIM CCW
– SW limit switch anticlockwise
3
0x0008
HW-LIM CW
– HW limit switch clockwise
4
0x0010
HW-LIM CCW
– HW limit switch anticlockwise
5
0x0020
CONT
– contouring error
6
0x0040
ENC
– Warning Absolute encoder
7
0x0080
User 1
– User Warning 1
8
0x0100
User 2
– User Warning 2
9
0x0200
(reserved)
10
0x0400
(reserved)
11
0x0800
(reserved)
12
0x1000
(reserved)
13
0x2000
(reserved)
14
0x4000
(reserved)
15
0x8000
(reserved)
For details on the warnings, refer to the frequency inverter Operating Instructions and
the “Positioning” application manual.
The Warning Bit 6 “Absolute encoder” can be read out via Parameter 1274 in VPlus or
1273 via field bus. The Absolute encoder warnings are described in detail in the Ex-
tension manual EM-ABS-01.
