bora X Pure User Manual

Technical data
EN
bora.com 105
3 Technical data
3.1 X Pure
Parameter Value
Multiphase supply voltage 380–415 V
2N/3N
Single-phase supply voltage 220–240V
Frequency 50–60 Hz
Maximum power consumption 7600W
(4400W/
3600W)
Three-phase power supply/
fuse protection
3 x 16 A
Two-phase power supply/
fuse protection
2 x 16A
Single-phase power supply/
fuse protection
1 x 32 A
(1 x 20 A /
1 x 16 A)
Dimensions (width x depth x height) 830 x 515 x 199
mm
Weight (incl. accessories/packaging) 23 kg
(PUXA)
24.5 kg
(PUXU)
Cooktop
Surface material Glass ceramic
Cooktop power levels 1–9, P
Front cooking zone size 230 x 230 mm
Front cooking zone output 2100 W
Front cooking zone power setting output 3000 W
Rear cooking zone size 230 x 230 mm
Rear cooking zone output 2100 W
Rear cooking zone power setting output 3000 W
Cooktop energy consumption (pan size)
Front left cooking zone (150mm) 179.4Wh/kg
Rear left cooking zone (180mm) 176.2Wh/kg
Left bridged cooking zones (240mm) 191.5Wh/kg
Front right cooking zone (150mm) 174.7Wh/kg
Rear right cooking zone (180mm) 177.5Wh/kg
Right bridged cooking zones (240mm) 197.1Wh/kg
Total (average) 182.7Wh/kg
Parameter Value
Exhaust air system
Cooktop extractor power levels 1–9, P
Exhaust air connection BORA Ecotube
Recirculation system
Cooktop extractor power levels 1–9, P
Size of exhaust opening (W x H) 445 x 137 mm
Activated charcoal filter service life 150 hrs (1 year)
Tab.3.1
Technical data for X Pure
3.1.1 PUXA appliance dimensions
Fig.3.1
PUXA appliance dimensions top view
Fig.3.2
PUXA appliance dimensions front view

bora X Pure Specifications

General

Product name	bora X Pure
Type	Induction
Integrated extractor	Yes
Power levels	9
Boost Function	Yes
Child Lock	Yes
Timer	Yes
Residual Heat Indicator	Yes
Color	Black
Product type	Cooktop
Control type	Touch
Frequency	50 Hz
Material surface	Glass ceramic
Supply voltage	230 V
Air recirculation	Optional
