Cleaning and maintenance
EN
130 bora.com
[1]
Stainless steel grease filter
[2]
Handle
[3]
Inlet opening
7.4.2
Cleaning the air inlet nozzle
and stainless steel grease
filter
If the stainless steel grease filter can no longer
be fully cleaned, it must be replaced (Warranty,
technical service, spare parts, accessories).
Manual cleaning
u
Use a cleaner and degreaser in one.
u
Rinse the components with hot water.
u
Clean the components with a soft brush.
u
Rinse the components well after cleaning.
Cleaning in the dishwasher
u
Remove coarse food residues from the components.
u
Place the components in the dishwasher.
u
No water should be able to gather in the
components.
u
Rinse the components with a rinsing program at a
maximum temperature of 65°C.
To prevent water from dripping into the
appliance, it is recommendable to shake the
nozzle well upon removal from the dishwater
and, if necessary, to dry it with a tea towel.
7.4.3
Fitting the components
Inserting the stainless steel grease filter
u
Take hold of the stainless steel grease filter by the
handle.
u
Insert the stainless steel grease filter in the inlet
opening. A lock is not provided or necessary.
Inserting the air inlet nozzle
u
Insert the air inlet nozzle in the inlet opening.
u
Make sure it is positioned correctly.
7.4.4
Removing liquids from the
appliance
Any liquids that flow into the appliance through the inlet
opening are caught by the stainless steel grease filter
(up to 150 ml) and in the air guiding housing.
Do the following:
u
Switch off the fan and deactivate the after-run
function.
u
Remove the air inlet nozzle and stainless steel grease
filter.
u
Empty the stainless steel grease filter.
u
Check whether any liquid has gathered in the base of
the air guiding housing.
u
If necessary, wipe the liquid up from the housing
base from above through the inlet opening using a
sponge or cloth.
u
Clean the air guiding housing.
u
To dry the activated charcoal filter and duct parts
respectively, switch on the cooktop extractor at a
minimum power level of 5.
T
After 120 minutes the cooktop extractor will
automatically switch to the automatic after-run
function.
7.5
Cleaning the air guiding
housing
Grease particles and limescale residues from cooking
vapours can settle on the surface of the air guiding
housing. For this reason, regular cleaning is essential.
The air guiding housing can be found on the bottom of
the cooktop inside the floor unit.
Opening the air guiding housing
u
Make sure that the cooktop and cooktop extractor
are switched off.
u
Wait until the fan display shows .
u
Remove the air inlet nozzle and stainless steel grease
filter.
u
Inside the inlet opening pull the filter replacement
cover out through the opening in the filter housing.
u
Hold the housing base with one hand.
u
Release the 6 locks around the edge of the base.
u
Remove the housing base.
u
Clean the air guiding housing and the housing base
with a mild cleaning agent.
