bora X Pure User Manual

Functions and operation
EN
bora.com 113
5 Functions and operation
u Observe all safety and warning information
(see"2Safety").
The integrated cooktop extractor must not be
used with other cooktops.
The cooktop should only be operated when the
filter replacement cover, stainless steel grease
filter and air inlet nozzle are installed (as well as
the activated charcoal filter in the recirculation
model).
5.1 General operating
instructions
The cooktop extractor and cooktops are operated via a
central operating panel. The operating panel is fitted
with electronic sensor buttons and display panels. The
sensor buttons respond to finger contact. You operate
the appliance by tapping the corresponding sensor
button with your finger (touch control) or by a swipe of
your finger (slider operation).
5.2 Touch control
The system recognises different touch commands. It
differentiates between a brief touch (tap), a prolonged
touch (long press) and vertical sliding movements with
your finger (swiping).
Touch
commands
Applicable to Time (contact)
Tap Buttons + slider 0.3 s
Long press Buttons + slider 1–8 s
Swipe Slider 0.1–8 s
Tab.5.1
Touch control
5.3 Function overview
The X Pure and Pure cooktops with integrated cooktop
extractor have the following features and functions:
Features PUXA PUXU PURA PURU
Electronic power adjustment 3 3 3 3
Short-time timer (egg timer) 3 3 3 3
Cooktop extractor functions
Automatic extractor function 3 3 3 3
Automatic after-run 3 3 3 3
Power setting 3 3 3 3
Filter service display 3 3
Cooktop functions
Automatic heat up function 3 3 3 3
Pan size recognition 3 3 3 3
Permanent pan size recognition 3 3 3 3
Heat retention function 3 3
Variable heat retention function 3 3
Bridging function 3 3
Automatic bridging function 3 3
Cooking zone timer 3 3 3 3
Pause function 3 3 3 3
Power setting 3 3 3 3
Safety features
Child lock 3 3 3 3
Operating lock 3 3 3 3
Cleaning lock 3 3 3 3
Residual heat indicator 3 3 3 3
Safety shut-down 3 3 3 3
Overheating protection 3 3 3 3
Tab.5.2
Function overview
5.4 Operating the system
5.4.1 Switching on
u Long press on the power button .
T The switch-on animation is displayed in the slider.
T If start-up is successful, the standard display will
appear in the operating panel.

bora X Pure Specifications

General

Product name	bora X Pure
Type	Induction
Integrated extractor	Yes
Power levels	9
Boost Function	Yes
Child Lock	Yes
Timer	Yes
Residual Heat Indicator	Yes
Color	Black
Product type	Cooktop
Control type	Touch
Frequency	50 Hz
Material surface	Glass ceramic
Supply voltage	230 V
Air recirculation	Optional
