Installation
EN
bora.com 151
[1]
Power supply
[2]
Power supply cover
[3]
Mounting eyes
9.9
Initial operation
During initial operation some basic settings
(basic configuration) must be applied using the
dealer and service menu.
9.9.1
Dealer and service menu
The dealer and service menu can be called up
up to 2 minutes after the appliance has been
connected to the power supply.
The system adopts and saves the settings made
when you exit the corresponding menu item.
Below you will find explanations on how to use
the menu and a description of the most
important menu items.
Dealer and service menu overview
Menu item/Description/
Selection area
Factory setting
B Extraction system
(exhaust air/
recirculation
system)
Recirculation
C Power
management
D Demo mode Off
Tab.9.3
Menu overview
Calling up the dealer and service menu
u
Connect the appliance to the power supply.
T
The standard display appears and the fan symbol
pulses for 2 minutes.
u
Long press on the fan button .
T
4 input points are shown.
u
Keep the fan button pressed and at the same
time press the input points in the specified order.
T
Menu item B is displayed.
Fig.9.47
Calling up the dealer and service menu
9.9.2
Menu item B: Extraction
system configuration
The extraction system must be configured.
There are two operating modes to choose from:
T
Operating mode : recirculation system (factory
setting)
T
Operating mode : exhaust air system
u
Select the corresponding operating mode (tap the
corresponding segment on the slider ).
u
Confirm and save the setting by moving to the next
menu item (tap the multi-function display/indicator
).
Fig.9.48
Display Menu item B: Configuring the
extraction system
