bora X Pure User Manual

Energy data sheets
EN
158 bora.com
Manufacturer BORA
Sound pressure level at minimum available speed in
normal operation**
– 28.6 27.5 LpA in dB re 20
µPa
Sound pressure level at maximum available speed in
normal operation**
– 53.8 53.2 LpA in dB re 20
µPa
Sound pressure level when operating on the intensive
level or fast mode level (power setting)**
– 56.0 55.1 LpA in dB re 20
µPa
Power consumption
Power consumption in off mode P
o
0.18 0.12 W
Power consumption in standby mode P
s
* * W
Tab.12.1
Energy labelling
* Does not apply to this product.
** Voluntary declaration
The sound pressure level has been determined from a distance of 1 m (distance-dependent level recording) on the
basis of the sound power level established under EN60704-2-13.
12.2 Energy datasheet for X Pure
Product information according to Commission Delegated Regulation (EU) No. 65/2014 and Regulation (EU) No. 66/2014.
Manufacturer BORA
Model identification PUXA/PUXU
Type of hob Glass ceramic
cooktop
Symbol Unit
Heating technology – Induction cooking
area
–
Number of cooking areas – 4 –
Front left cooking area LxW 23x23 cm
Front right cooking area LxW 23x23 cm
Rear left cooking area LxW 23x23 cm
Rear right cooking area LxW 23x23 cm
Front left cooking area EC
electric cooking
179.4 Wh/kg
Front right cooking area EC
electric cooking
174.7 Wh/kg
Rear left cooking area EC
electric cooking
176.2 Wh/kg
Rear right cooking area EC
electric cooking
177.5 Wh/kg
Left bridged cooking areas EC
electric cooking
191.5 Wh/kg
Right bridged cooking areas EC
electric cooking
197.1 Wh/kg
Energy consumption of the hob per kg EC
electric hob
182.7 Wh/kg
Tab.12.2
Energy datasheet for X Pure

bora X Pure Specifications

General

Product name	bora X Pure
Type	Induction
Integrated extractor	Yes
Power levels	9
Boost Function	Yes
Child Lock	Yes
Timer	Yes
Residual Heat Indicator	Yes
Color	Black
Product type	Cooktop
Control type	Touch
Frequency	50 Hz
Material surface	Glass ceramic
Supply voltage	230 V
Air recirculation	Optional
