Cleaning and maintenance
EN
bora.com 131
Fig.7.4
Air guiding housing
[1]
Air guiding housing
[2]
Housing base
[3]
Spigot
[4]
Sealing groove
[5]
Lock
Closing the air guiding housing
u
Position the housing base under the air guiding
housing with the help of the 3 spigots.
u
Push the housing base upwards into the sealing groove.
u
Close the 6 locks.
u
Check that the housing base is positioned correctly.
u
Inside the inlet opening push the filter replacement cover
until it comes to a stop in the filter housing opening.
u
Check that the filter replacement cover is positioned
correctly.
u
Insert the stainless steel grease filter and the air inlet
nozzle.
7.6
Replace the activated
charcoal filter
An activated charcoal filter will only be fitted with the
stainless steel grease filter if the cooktop extractor is
used in recirculation mode. The activated charcoal filter
absorbs cooking odours that arise during cooking. The
activated charcoal filter must be replaced when the fan
display shows (Filter service indicator).
u
Make sure that the cooktop and cooktop extractor
are switched off.
u
Wait until the fan display shows .
You can obtain activated charcoal filters from
your specialist supplier or from the BORA Shop
via the website at http://www.mybora.com.
Removing the activated charcoal filter
u
Remove the air inlet nozzle and stainless steel grease
filter.
u
Inside the inlet opening pull the filter replacement
cover out through the opening in the filter housing.
Fig.7.5
Removing the filter replacement cover
[1]
Filter replacement cover
[2]
Inlet opening
u
Take hold of the activated charcoal filter by the grip
strap and pull it out as far as possible through the
filter housing opening.
Fig.7.6
Removing the activated charcoal filter from
the filter housing
[1]
Grip strap
[2]
Activated charcoal filter
