Setup Menu Options
The Setup Menu contains seven sub-menu options for formatting and printing your labels and
setting your language preference for the menus and prompts. Many of these options provide
you with ways to customize the formatting of your labels. Refer to the Setup Menu Tree
section on page
17.
Printer
The Printer Menu contains the following user options:
Option Description
Top Margin Adj. Adjusts first vertical print position from top of label. Values range
from -0.625 mm (-0.0246 in) to +1.375 mm (0.05412 in).
Left Margin Adj. Adjusts first horizontal print position from left edge of label.
Values range from -0.625 mm (-0.0246 in) to +1.375 mm
(0.05412 in).
Cut Feed Adj. Adjusts vertical cut position between labels. Values range from -1
mm (-0.03936 in) to +1 mm (0.03936 in). The <▲> and <▼> keys
increase/decrease value by 0.125 mm increments (1 dot).
Peel Time Determines how long (in seconds) a label remains in peel position
before moving back to cut position. Ranges from 2 to 9 seconds.
Default = 5 sec.
Note: Peel time option is not supported for BRADYSleeve and
PermaSleeve marker parts.
Burn Temp Determines the print density on the label. Setting ranges from -5
(lightest) to + 5 (darkest). Default = 0
Clean Printer Performs printer cleaning routine. Use this option with the cleaning
card shipped with the unit.
Barcode
The Barcode Menu contains the following user options:
Option Description
Bar Height Sets the height of the Code 39 barcode. Setting ranges from 1 mm
(0.03937 in) to 26 mm (1.02362 in). Default = 1 mm. Narrow bar
width = 2 dots (.25 mm). Barcode Ratio = 2 to 1.
Human
Readable
Determines whether the barcode is printed along with human readable
text. Toggles between on and off. Font size ranges from 2 (5 point) to
9 (14 point). Default = off.
Bar Code Type Determine type of bar codes:
• Code_39
• Code_128
• ITF_25
• Codabar
TLS2200
™
Thermal Transfer Printer User Manual 13
