Continuous Printing—Terminal Block Labels
This section discusses making terminal block labels with the TLS2200
printer.
Creating Terminal Block Labels
Terminal block labels can be created and printed using the TLS2200 printer. Simply choose
the appropriate center-to-center spacing repeat (pitch) for the block, enter your text, and print
as needed. The number of lines of text available at each termination is dependent on repeat
value spacing and the font size chosen.
Setting the Center-to-Center Spacing
The center-to-center spacing (terminal block repeat) is set by accessing the Term Repeat option
on the Setup Menu. Follow the instructions below to set this option:
1. Press the <Func> + <Setup> keys to access the Setup Menu.
2. Press the <
> key two times to scroll to the Continuous Menu, press the <Enter> key.
3. With the cursor on the Terminal Block option, press <Enter>.
4. Use the arrow keys to adjust the terminal block repeat value, then press <Enter>.
The repeat can be set from 2 mm (0.19685 in) to 46 mm (1.81102 in). Press the <
> and
<
> keys to increase/decrease the repeat value by 0.125 mm increments (1 dot). Press the
<Shift> + <
> and <Shift> + <> to increase/decrease the repeat value by 1 mm
increments (8 dots).
Note: Press <Feed> after printing to advance the terminal strip label to the cut
position.
TLS2200
Thermal Transfer Printer User Manual 33
