Brady TLS2200 User Manual

T8: Creating a Terminal Block Label
Note: This example assumes you have the terminal block marker roll PTLTB-400-375
loaded in your printer.
Label to be printed:
101
102
103
104
105
106
107
108
109
110
Setup Status:
Center
H Justify
Center
V Justify
0 Degrees
Rotation
Component
Format
Text
Legend Type
1. Press <Shift> + <Form Clear> to delete all lines of text and reset the font to the default
value of 6.
2. Press <Func> + <Setup> to access the Setup Menu.
3. Press the <
▼> key six times to select Units, then press <Enter>.
4. Press the <▲> or <▼> keys to toggle the Units to Metric, then press <Enter>.
5. Press the <
▲> key four times to select Continuous, then press <Enter>.
6. With the cursor highlighted on Terminal Block, press <Enter>.
7. Use the <▲> and <▼> keys as needed to set the terminal block repeat value to 6 mm
(.23622 in.), then press <Enter>.
8. Press <Func> + <Exit> to exit back to the Text Editor screen.
9. With the cursor highlighted on line one, press <Shift> + <
▲> once to increase the font
size from 6 to 7.
10. Enter 101 on line one.
11. Press <
◄>.
TLS2200
™
Thermal Transfer Printer User Manual 45
